Sun-display

SC80A

1.CPU:MTK6771,Octa core,2.0GHZ
2.RAM/ROM:4GB+64GB
3.Support Gravity Sensor \ Compass \ Gyro \ Light sensitive \ Distance sensing
4.Supports WIFI/BT/GPS
5.Supports 2G/3G/4G communication
6.Supports NFC
7.Support 1D/2D scanner/Fingerprint
8.Battery:0000mAh, 3.8v high voltage lithium battery
9.Camera:Front camera: 5MP fixed focus Rear camera: 13MP auto focus 1A true flash
10、OS:Android 10
11、Screen Resolution1920*1200
12、Screen Brightness:700cd/㎡




Brand
SUN-DISPLAY
Model
SC80A
Size weight
227*142.4*22.9mm/810g
color
Black, color can be customized
screen size
8inch
screen resolution
800*1280, IPS 1280*800, 1920*1200 can be customized in batches
screen brightness
450cd/㎡, can be customized 1000cd/㎡
TP touch screen
10-point touch G+G, hardness ≥6H, support wet hand touch screen, glove touch screen
Battery
10000mAh, 3.8v high voltage lithium battery, non-removable, battery life per day ≥10h (1080P+50% brightness)
Camera
Front camera: 5MP fixed focus (13 million can be customized in batches)
Rear camera: 13MP auto focus 1A true flash
Buttons
Power button*1 Volume keys*2, Vol+, Vol- Custom keys*2, P key, F key
Hardware configeration
Speaker, receiver, microphone
*2, speaker 1.2W/8Ω aluminum film, waterproof speaker;
*1, waterproof handset
*1, MIC,waterproof rating
CPU
MTK6771,octa core,2.0GHZ
RAM
4GB(optional 8GB)
ROM
64GB(optional128GB)
Gravity sensor
YES
Compass
YES
Gyro
YES
Light-sensitive
YES
distance sensing
YES
Fm Radio
YES
Date collection
1D/QR code
(function customizable)
ID card (custom function)
Standard second-generation offline Ministry of Public Security certified ID card reader module
UHF (custom function)
PR9200,distance1:1.5M-3M:
distance2:5M-8M
R2000,distance10M-18M
High frequency (custom function)
13.56MHZ adapt 14443A/14443B/15693 protocals
Fingerprint (custom function)
1: Ordinary industrial fingerprint
2: Fingerprint certified by the Ministry of Public Security
3: FBI certified fingerprint
Wireless connection
WIFI
WIFI 802.11(a/b/g/n/ac) frequency 2.4G+5.8G dual-band WIFI Dual frequency WIFI
Short range radio
4.2 (BLE) class1 transmit distance:10m
2G/3G/4G
GSM: B2/B3/B5/B8
WCDMA: B1/B2/B5/B8
TD-SCDMA:B38/B39/B40/B41
CDMA2000
LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B28A/
LTE-TDD: B38/B39/B40/B41
GPS
GPS、Beidou, Galileo、GLONASS
NFC
I²C interface, 13.56MHZ supports 14443A/14443B/15693 and other protocols, which is consistent with the NFC application of Android
phone type
(The card reading area is default on the back of the fuselage and can be customized in the front)
Ports
TYPE-C
*1,Type-C USB2.0 adapt OTG
Type -A
*1,Type-A USB2.0
Earphone Jack
*1,3.5mmStandard headphone jack
TF Card
*1,Maximum support 256GB expansion
SIM Card
*1,Standard Micro SIM card slot
MINI HDMI
*1,Mini HDMI
DC port
*1, 5V/3A (DC plug outer diameter 3.5mm inner diameter 1.5mm)
POGO PIN
*1 ,12Pin USB+charger
Product reliability
Drop height
1.2m Free fall to wooden floor
Working temperature
‘-20℃~60℃
Storage temperature
’-30℃~70℃
Humidity
Humidity: 95% Non-Condensing
Certificates
IP67, 3C, CE, MIL-STD-810 certification, energy saving certification, ISO quality certification system, ROHS,
three-proof salt spray test
CE-NB
YES
MIL-STD-810G
YES
CCC
YES
Adapter
5V/3A,DC interface adapter
